i-FREEFALL 5100 Free Falling/Drop Dart Impact Tester is designed for determination of the impact resistance property of the plastic film or sheet under the impact of falling ball of specified weight from a specified height.

i-FREEFALL 5100 Free Falling/Drop Dart Impact Tester is designed for determination of the impact energy (which is expressed in term of mass) when 50% of the test film or sheet which are of less than 1mm thickness impacted by the missile falling from the specified height.
Test Method A: The specified height of free falling is 660 mm and the impact mass is within the range of 50-2000 g.
Test Method B: The specified height of free falling is 1500 mm and the impact mass is within the range of 300-2000 g.

i-FREEFALL 5100 Free Falling/Drop Dart Impact Tester can be used with our advanced Online Data Management System for packaging testing, which comes with two versions to meet distinct needs of our clients: The Cloud Version & The Intranet Version

Features:
1.Windows visual operating interface and TFT touch screen are convenient for settings of test parameters.
2.2 test methods including Test Method A and Test Method B and automatic judgment of test status.
3.Electromagnetic suspension of dart release mechanism effectively reduces the errors caused by manual operation.
4.Pneumatic clamping, 2 starting modes of manual and pedal switch and built-in observation light are convenient to the user's operation.
5.Professional software supports multi-unit result display and printing functions which is convenient for users to review test data.
6.Test data can be printed out by the micro printer.

Applications:
1.Films
2.Aluminum Foil and Aluminum Plastic Composite Films
3.Paper and Paper Board
4.Falling Ball Test

Technical Specification:
Test Range Method A: 502000 g
           Method B: 3002000 g
Test Accuracy:0.1 g(0.1 J)
Clamped By Pneumatic Control
Specimen Size >150 mm x 150 mm

i-FREEFALL 5100 Free Falling/Drop Dart Impact Tester conforms to the following standards:ASTM D1709, JIS K7124-1-1999, GB/T 9639.1-2008,ISO 7655-1-1988

Detailed information,pls contact Emily Wu at sales#labthinkinternational.com or Tel: (+1) 617-830-2190
